Switch Cisco Catalyst C1300-24T-4G là một trong những dòng switch quản lý cấp doanh nghiệp, mang lại hiệu suất cao, khả năng mở rộng linh hoạt và bảo mật tối ưu cho hệ thống mạng. Với 24 cổng Gigabit Ethernet (10/100/1000 Mbps) và 4 cổng uplink SFP quang tốc độ cao, thiết bị này phù hợp cho các doanh nghiệp vừa và nhỏ, văn phòng, trường học và hệ thống mạng yêu cầu băng thông lớn.
✅ Hiệu suất cao: Với 24 cổng Gigabit, thiết bị đảm bảo tốc độ truyền tải dữ liệu nhanh chóng và ổn định, giúp giảm thiểu tắc nghẽn mạng.
✅ Kết nối linh hoạt: 4 cổng SFP hỗ trợ kết nối quang tốc độ cao, mở rộng hệ thống mạng dễ dàng.
✅ Bảo mật nâng cao: Hỗ trợ các tính năng bảo mật tiên tiến như 802.1X, ACLs, DHCP Snooping, giúp bảo vệ mạng khỏi các cuộc tấn công.
✅ Quản lý dễ dàng: Giao diện quản lý web thân thiện, hỗ trợ CLI, SNMP, và tích hợp với Cisco DNA Center để tối ưu vận hành.
✅ Tiết kiệm năng lượng: Công nghệ Cisco EnergyWise giúp giảm mức tiêu thụ điện năng mà không ảnh hưởng đến hiệu suất.
🔹 Kết nối hệ thống mạng nội bộ cho doanh nghiệp, văn phòng, trường học.
🔹 Mở rộng hệ thống mạng với đường truyền quang tốc độ cao.
🔹 Đảm bảo hiệu suất ổn định cho các ứng dụng quan trọng như VoIP, video conference, dữ liệu lớn.
Switch Cisco Catalyst C1300-24T-4G là sự lựa chọn lý tưởng cho những doanh nghiệp cần một giải pháp mạng mạnh mẽ, an toàn và linh hoạt. Nếu bạn đang tìm kiếm một switch chất lượng cao với giá thành hợp lý, đây chắc chắn là một sản phẩm đáng cân nhắc! 🚀
Port | 8 x 1 Gigabit Ethernet 2x Gigabit copper/SFP combo ports |
Console port | Cisco standard RJ-45 console port and USB Type C port |
USB port | USB Type C port on the front panel of the switch for easy file and image management as well as console port |
Performance | |
Switching capacity in Gigabits per second (Gbps) | 20 Gbps |
Capacity in Millions of Packets Per Second (mpps) (64-byte packets) | 14.88 Mpps |
Hardware | |
CPU | ARM dual-core at 1.4 GHz |
DRAM | 1 GB DDR4 |
Flash | 512 MB |
Packet buffer | 1.5 MB |
Buttons | Reset button |
Cabling type | Unshielded Twisted Pair (UTP) Category 5e or better for 1000BASE-T |
LEDs | System, Link/Act, PoE, Speed |
Feature | |
Spanning Tree Protocol | Standard 802.1d Spanning Tree support Fast convergence using 802.1w (Rapid Spanning Tree [RSTP]), enabled by default Multiple Spanning Tree instances using 802.1s (MSTP); 8 instances are supported Per-VLAN Spanning Tree Plus (PVST+) and Rapid PVST+ (RPVST+); 126 instances are supported |
Port grouping/link aggregation | Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP) ● Up to 8 groups ● Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad link aggregation |
VLAN | Support for up to 4093 VLANs simultaneously Port-based and 802.1Q tag-based VLANs, MAC-based VLAN, protocol-based VLAN, IP subnet-based VLAN Management VLAN Private VLAN with promiscuous, isolated, and community port Private VLAN Edge (PVE), also known as protected ports, with multiple uplinks Guest VLAN, unauthenticated VLAN Dynamic VLAN assignment via RADIUS server along with 802.1X client authentication Customer premises equipment (CPE) VLAN Auto surveillance VLAN (ASV) |
Voice VLAN | Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS. Voice Services Discovery Protocol (VSDP) delivers networkwide zero-touch deployment of voice endpoints and call control devices |
Multicast TV VLAN | Multicast TV VLAN allows the single multicast VLAN to be shared in the network while subscribers remain in separate VLANs. This feature is also known as Multicast VLAN Registration (MVR) |
IPv4 routing | Wire-speed routing of IPv4 packets Up to 990 static routes and up to 128 IP interfaces |
IPv6 routing | Wire-speed routing of IPv6 packets |
Layer 3 interface | Configuration of a Layer 3 interface on a physical port, LAG, VLAN interface, or loopback interface |
Routing Information Protocol (RIP) v2 | Support for RIP v2 for dynamic routing |
Policy-Based Routing (PBR) | Flexible routing control to direct packets to a different next hop based on an IPv4 or IPv6 Access Control List (ACL) |
DHCP server | Switch functions as an IPv4 DHCP server, serving IP addresses for multiple DHCP pools or scopes Support for DHCP options |
Environmental | |
Unit dimensions (W x H x D) | 268 x 185 x 44 mm (10.56 x 7.28 x 1.73 in) |
Unit weight | 1.39 kg (3.06 lb) |
Power | 100-240V 50-60 Hz |
Certification | UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A |
Operating temperature | 23° to 122°F (-5° to 50°C) |
Storage temperature | -13° to 158°F (-25° to 70°C) |
Operating humidity | 10% to 90%, relative, noncondensing |
Storage humidity | 10% to 90%, relative, noncondensing |
Fan (number) | Fanless |
MTBF at 25°C (hours) | 2,171,669 |
