• Full duplex 4 channel 1310nm parallel module
• SFF-8436 QSFP+ compliant
• Hot pluggable electrical interface
• Differential AC-coupled high speed data interface
• 4 channels 1310nm DFB laser
• 4 channels PIN photo detector array
• Maximum link length of 10km on G652
• Single male MPO(APC 8-degree) connector receptacle
• Maximum power consumption 2.5W
• Housing isolated from connector ground
• Operating case temperature 0°C to +70°C
• 3.3V power supply voltage
• RoHS 6 compliant

Applications

• Infiniband Connectivity SDR/DDR/QDR
• 10GBASE-LR/W 10G Ethernet
• 2/4/8 Gbps Fiber Channel
• Data Centers and Storage Arrays
