| Part Number | JL807A |
| Description | Aruba Instant On 1960 24G 20p Class4 4p Class6 PoE 2XGT 2SFP+370W Switch |
| Downlink Ports | 2 SFP+ 10GbE ports 2 10GBASE-T ports |
| Uplink Ports | 24 RJ-45 autosensing 10/100/1000 Mbps ports including 4 CL4 and 20 CL6 PoE ports |
| Physical Characteristics | |
| Dimensions | 350.5(d) x 442.5(w) x43.95(h) mm |
| Weight | 10.4 lb (4.7 kg) |
| CPU | Single-Core ARM v7 Cortex-A9 @800MHz |
| Performance | |
| Throughput (Mpps) | 95 Mpps |
| Capacity | 128 Gbps |
| Routing Table size (# of static entries) | 32 IPv4/IPv6 |
| MAC Address table size (# of entries) | 16,000 entries |
| Reliability MTBF (years) | 65.3 |
| Device Management | Aruba Instant On Cloud;Web browser; SNMP Manager |
| Environment | |
| Operating temperature | 0-40°C, 0-10,000 ft |
| Operating relative humidity | 15% to 95% @ 104°F (40°C) non-condensing |
| Nonoperating/Storage temperature | -40°F to 158°F (-40°C to70°C) up to 15000 ft |
| Electrical Characteristics | |
| Frequency | 50Hz/60Hz |
| AC voltage | 100-127VAC /200-240VAC |
| Current | 5.0A/0.4A |
| Maximum power rating | 100-127V: 500W 200-220V: 480W |
| Idle power | 100-127V: 40W 200-220V: 80W |
| PoE power | Total 370 W PoE Power (Up to 240 W of Class 6 or 370 W of Class 4 PoE) |
| Power Supply | Internal power supply |
